MITEQ’s Triple Threat To Compliance Testing @ EMC 2013 (Event—Technology Showcase)

[SatNews] Join this Company in Denver, Colorado to view their wide array of…

products that can be of assistance in the EMI testing that’s required by commercial, medical, automotive and military customers. MITEQ will be at EMC 2013 in Denver, Colorado, from August 5th through the 9th at Booth #216.

MITEQ’s new Model TTA Series are high performance Broadband Low Noise Amplifiers specially developed for Electromagnetic (EMC) compliance testing. Complete frequency coverage from 1MHz to 40GHz is possible with three separate TTA amplifiers. They are enclosed in a small [5.1″ L x 3.5″ W x 1.9″ H] lightweight EMI/RFI case and can be used easily in the EMC test setup. A universal wall plug in power supply is included with each TTA which operates from 50-60 Hz / 100-240 VAC. CE approved. These new TTA Series offerings are small and lightweight, offer simple plug and play, and come with the standard MITEQ three year warranty. There are also a number of options available that can be included at the time of the order.

The company’s Low-Noise Block Converters with RF coverage of 18-40GHz convert to IF frequencies into the range of existing equipment. These wide RF/IF bandwidth frequency converters, with fixed LO frequencies (block converters), are commonly used to process millimeter wave signals with less expensive receivers below 18GHz.

The LNB series, with its 4dB noise figure permits operation at low input signal powers. In addition, the PM noise of the converter is minimized by a phase-locked and multiplied internal LO source. RF frequency gaine range is 26 to 40GHz, the conversion gaine is 42dB typical, and the noise figure is 4dB maximum.

Providing EMI immunity are MITEQ’s fiber optic links, offering a high dynamic range [>100dB] for transmission of low level signals over a long distance—without interference. MITEQ´s LNBF-2440-05 Low-Noise Block Converter offers a very wide instantaneous bandwidth of 16GHz. The LNBF unit incorporates a fixed frequency 42GHz Phase Locked Local Oscillator and Low Phase-Noise OCXO.

Reference Oscillator to convert the full 24 to 40GHz RF-band down to a 2 to 18GHz IF-band. The unit also includes a 16GHz instantaneous bandwidth fiber optic transmitter. The LNBF is packaged in a 5¨ x 5¨ ruggedized aluminum housing with an integrated heatsink. The SCMR-18G optical receiver unit is packaged in a miniature 0.8¨ x 0.7¨ housing. Standard optical connectors are FC/APC type.
