…Solid State RF Amplifier Series, the PC1300-3C. This new product is a 3-channel Solid State RF Amplifier with independent channels, with each channel providing 1000 watts peak RF power. The RF amplifier is driven by a single customer supplied RF input signal. Power and phasing are manually adjusted via a front panel control as well as via a dB-25 coupled remote control.
The unit is ferrite isolator protected at the RF input and at each of the three RF outputs. The power of each channel is adjustable from max to -10 dB—the unit is completely self-contained and includes all of the power supplies as well as internal cooling.
The PC1300-3C lso offered in a complete stand-alone package that includes the internal source with the only customer requirement being the input trigger and AC voltage only; no RF signal is required. Multiple channels are available, depending on customer requirements. Output power is as low as 10 to 1000 Watts Peak.CW output power ranges from 10 to 250 Watts.
