While you might not picture a flat screen TV showing the Super Bowl on the Moon, or an astronaut blow drying their hair, their need for electricity is going to be very real. Therefore, in anticipation of NASA astronauts power source needs when they return to the moon and establish a lunar outpost, NASA engineers are exploring the possibility of nuclear fission to provide the necessary power. The engineers are also taking initial steps toward a non-nuclear technology demonstration of this type of system that would involve a fission surface power system on the moon that would have the potential to generate a steady 40 kilowatts of electric power, enough for about eight houses on Earth. It works by splitting uranium atoms in a reactor to generate heat that then is converted into electric power.
What makes the fission surface power system seem like the perfect solution is that it can produce large amounts of power in harsh environments, like those on the surface of the moon or Mars, because it does not rely on sunlight. The primary components of fission surface power systems are a heat source, power conversion, heat rejection and power conditioning, and distribution. A nuclear reactor used in space is much different than Earth-based systems. There are no large concrete cooling towers, and the reactor is about the size of an office trash can. The energy produced from a space reactor also is much smaller but more than adequate for the
projected power needs of a lunar outpost.
“Our goal is to build a technology demonstration unit with all the major components of a fission surface power system and conduct non-nuclear, integrated system testing in a ground-based space simulation facility,” said Lee Mason, principal investigator for the test at NASA’s Glenn Center in Cleveland, Ohio.
Glenn contracted for the design and analysis of two different types of advanced power conversion units as the initial step in the development of a full system-level technology demonstration. The first design concept by Sunpower Inc., of Athens, Ohio, uses two opposed piston engines coupled to alternators that produce 6 kilowatts each, or a total of 12 kilowatts of power. The second contract with Barber Nichols Inc. of Arvada, Colorado, is for development of a closed Brayton cycle engine that uses a high speed turbine and compressor coupled to a rotary alternator that also generates 12 kilowatts of power.
After a one year design and analysis phase, a single contractor will be selected to build and test a prototype power conversion unit. When complete, the power conversion unit will be integrated with the other technology demonstration unit’s major components. Glenn will develop the heat rejection system and provide the space simulation facility. Glenn also will work in conjunction with the Department of Energy and NASA’s Marshall Space Flight Center in Huntsville, Alabama. Marshall will develop and provide a non-nuclear reactor simulator with liquid metal coolant as the heat source unit for the technology demonstration.
Then, when they’ve gotten that far, the testing of the non-nuclear system is expected to take place at Glenn in 2012 or 2013. These tests will help verify system performance projections, develop safe and reliable control methods, gain valuable operating experience, and reduce technology and programmatic risks. This technology demonstration is being conducted as part of NASA’s Exploration Technology Development Program.
