AccelerComm, Radisys® Corporation, RFDSP Lower-Phy IP specialists and TTP are jointly formulating a high-performance, Regenerative 5G RAN reference solution and architecture based on 3GPP for deployment on LEO satellites.
This partnership combines expertise and IP from these companies, together with additional technology from partners, to propose a 5G regenerative gNodeB solution that is tailored to support high-performance 5G services in the challenging environment of a Non-Terrestrial Network (NTN).
In a typical LEO deployment, a constellation of fast-moving satellites covers a wide geographical area using a large number of beams per satellite to cover a multitude of subscribers. The 5G Regenerative NTN solution includes Option-2 split gNB with a distributed unit (DU) on the satellite payload with a ground-based, centralized unit (CU) and 5GC.
The solution handles unique regenerative NTN-specific requirements of extremely high mobility with frequency re-association between the DU, GW and CU serving a region and large-sized cells spanning multiple countries requiring country-specific CN routing. Moreover, any gNodeB platform for space applications will be highly constrained in size, weight, and power, and must be able to work in a hostile space environment.
The joint, LEO Regenerative reference solution will be designed to meet the growing demand for satellite-based eMBB (enhanced Mobile Broadband) and IoT (Internet of Things) services. This makes it an ideal solution for businesses and organizations that need to connect people and devices in remote locations, or for governments looking to provide internet access to all citizens.
The solution will support a large number of beams and high subscriber density and will be delivered on a space-hardened platform optimized for low power and size. It includes a range of advanced developments in the areas of beam-to-cell mapping, beam forming, NTN beam management and well-defined interfaces to SATCOM infrastructure.
The O-RAN compliant gNodeB leverages Radisys’ split, NTN-capable CU, DU software with AccelerComm’s LEOphy and RFDSP’s Low-Phy, a Layer 1 modem that delivers enhanced performance for LEO satellite communications combined with TTP’s DFE and Beam Scheduler. Radisys’ CU/DU supports optimized mechanisms for handling signaling load due to high mobility, along with a power-optimized scalable software that manages the varying system requirements of beams and users.
LEOphy boasts the lowest error rates, with dedicated features to overcome the specific challenges of NTN channels, such as high path losses, differential delays, Doppler shift, long propagation delays, and rapid fluctuations in signal amplitude and phase caused by atmospheric effects. As a result, it ensures a high-reliability link without having to resort to lower coding rates and low-order modulation schemes, thereby maximizing spectral efficiency.
TTP’s DFE supports Crest Factor Reduction (CFR) to improve the efficiency of the RF power amplifier and its Beam Scheduler enables optimized beam hopping and switching functionality to maximize network capacity based on real-time traffic demands.
The 5G Regenerative gNodeB is combined for an end-to-end, NTN solution, with Radisys’ 5GC, available on Kubernetes container platform and small form-factor x86, ARM, and which can handle both NR-NTN and IoT devices.
“Deploying 5G gNodeB on a LEO satellite payload, brings a unique set of challenges for satellites passing over at extremely high speeds, including large cell coverage optimization, high doppler handling and users’ mobility. With onboard regenerative deployments, the complexities compound. Onboard power and resource constraints require low compute, storage footprint CU, DU software and performance-efficient beam hopping that goes beyond 3GPP specifications. Radisys is excited to partner with AccelerComm, RFDSP and TTP to define and develop an NTN solution addressing the regenerative gNodeB challenges and enable their customers to deploy LEO constellation satellite services.” — Munish Chhabra, Senior Vice President and General Manager, Software and Services, Radisys
“There has been an explosion in interest around combining satellite and traditional mobile communications systems. However, for satellite 5G to be truly successful there are a number of performance and efficiency challenges which have to be overcome. Solving these requires building on the existing 3GPP technologies to create a tailored solution built to deal with the unique challenges of operating around a thousand kilometres from Earth at speeds of over 7km per second, all while dealing with power and resource constraints. We are delighted to be working with our partners Radisys, RFDSP and TTP to develop this high-performance solution which will open-up a whole new market for delivering 5G services from space.” — Rob Barnes, Chief Marketing Officer, AccelerComm
“A 5G NTN LEO regenerative gNodeB deployment presents unique challenges when compared to Terrestrial gNodeB. In order to serve the number of beams and support the density of subscribers required, the gNodeB will have to be heavily optimised and tightly integrated with the overall payload functionality.TTP is pleased to partner with AccelerComm, RFDSP and Radisys to define a highly scalable and low power gNodeB solution, that will enable LEO operators to efficiently deliver 5G NTN services.” — Peter Kibutu, TTP’s Advanced Technology Lead NTN
“Recognizing the growing demand for 5G physical layers for non-terrestrial applications and their unique requirements, based on our conformance-tested 5G NR low PHY for terrestrial networks, we built a fully-featured 5G low PHY solution for NTN including a unified interface with high PHY for both options 6 and 7.2x, Doppler shift compensation, digital front-end design, beamforming, and control of multiple simultaneous beams for maximal spectral efficiency. We are happy to be a part of the 5G NTN ecosystem.” — Prof. Ping Liang, founder and CEO, RF DSP Inc.
