World's First Drone Payload for RF Testing of SATCOM for Drones Delivered by AtlanTecRF

AtlanTecRF has launched their light-weight, rugged and compact Drone Payload Satellite Simulator.
This unique product provides a transmit (Tx) to receive (Rx) loop-back in testing mostly compact and mobile satellite communications systems in situ and without the need for connection via cables.

AtlanTecRF standard high performance LTT microwave circuits have been configured for installation, along with circularly polarized antennas at Ka-band and a rechargeable battery power pack into a specially designed and weatherproof housing capable of being carried by a moderately sized hovering drone. The drone is then flown into the line of sight of the SATCOM system antenna providing the loop-back and facilitating system and antenna testing and calibration without the need to go live on the satellite.
Test methods using other satellite simulator models can involve mounting the simulator test instrument on a mast or “cherry picker” to intercept the SATCOM system line of sight but such an arrangement can give rise to test site clutter and inconvenience in some circumstances. The Drone Payload avoids this scenario and also has the advantage of being able to provide the loop-back from heights above the ground which would be simply impractical by other methods. With a fixed local oscillator frequency and pre-adjusted conversion gain, the drone-borne satellite simulator carries out a dedicated and defined task for Ka-band antenna testing, such as might be found in aircraft based communication sets or other difficult to access systems.

While the launch product is designed specifically for the Ka-band 30GHz uplink and 20GHz downlink markets, similar drone-capable payloads are possible for Ku-band and DBS bands. The internal rechargeable battery lasts at full test power for up to two hours, which is usually adequate to carry out a system alignment test and matches the typical drone battery endurance.
The C.E.O. of AtlanTecRF, Geoff Burling, noted that the system test engineer is offered the advantages of all the very latest technologies and, therefore, the firm's policy of enhancing both ease-of-use and effectiveness in the SATCOM RF test products continues. It is only natural that hovering drones are enabled to deliver this level of convenience to the test engineer.
