Utah Scientific… Dot.Box Is Extended… (SatBroadcasting™)

Utah Scientific has extended their Dot.Box family, a combined dual-channel master control and routing system that constitutes a complete, affordable solution for broadcasters moving to multichannel operation. The Dot.Box package, originally available with 32×32 and 64×64 router frames, has now been extended to include a 144×144 frame size — both the Dot.Box 64 and 144 are wired for future expansion of inputs, outputs, and master control channels.

Dot.Box makes multichannel operation easy to implement, manage, and maintain — all at a surprisingly low cost. And with the new addition, the package can accommodate a wider range of routing requirements and facilitate the addition of more master control channels. The Dot.Box packages consist of a UTAH-400 HD/SD routing switcher with 32 inputs and 16 outputs and two MC-400 master control processor boards with MCP-400 master control panels — everything necessary to put two SD/HD switchable channels on air.

For reliability, the router incorporates dual power supplies and dual crosspoint/controller boards. The two MC-400 processors are housed in the router frame with access to all 32 sources and also feature internal logo keying and external key signal inputs, automatic EAS message presentation, video frame buffers on the master control video inputs, and an independent MCP-400 physical control panel for each master control channel. Router control is handled by the uniquely flexible SoftPanel-2 virtual control panel system, which allows the user to create and deploy virtual panels to meet any control requirement.
